Fitler

Fitness Data Integration Made Simple

Sync your activity data across Strava, Garmin, RideWithGPS, and spreadsheets.

Get Started

Fitler

Fitler is a Python toolkit for aggregating, syncing, and analyzing your fitness activity data from multiple sources (Strava, RideWithGPS, spreadsheets, and local files). It is designed to be self-contained, non-destructive, and extensible.

🌐 Website: fitler.net 📦 PyPI: pypi.org/project/fitler 📚 Source: github.com/ckdake/fitler[CAUTION: This is under active development. Do not use it without reading every line of code!]

ruff pytest mypy deploy-site

Features

  • Parse and import activity files (.fit, .tcx, .gpx, and compressed variants)
  • Integrate with Strava and RideWithGPS APIs
  • Store and manage activity metadata in a local SQLite database
  • Command-line interface for authentication and data management
  • Web dashboard for viewing configuration and database status (./dev.sh)
  • Modular provider and file format architecture for easy extension
  • Static website with documentation at fitler.net

Quick Start

Option 1: Development Container (Recommended)

The easiest way to get started is using the provided development container:

  1. Prerequisites: Install VS Code and Docker
  2. Open Repository: Clone and open in VS Code
  3. Reopen in Container: When prompted, click "Reopen in Container" or use Ctrl+Shift+P → "Dev Containers: Reopen in Container"
  4. Wait for Setup: The container will automatically install all dependencies and run verification tests
  5. Start Developing: Everything is ready to go!

📋 See .devcontainer/README.md for detailed container documentation.

Verify Setup:

.devcontainer/verify.sh  # Quick environment check
python -m fitler --help  # Test CLI access

Option 2: Local Installation

  1. Clone the repository:

    git clone https://github.com/ckdake/fitler.git
cd fitler

  2. Install dependencies:

    pip install -e .[dev]  # Development installation
# OR
pip install .          # Regular installation

  3. Set up development tools:

    pre-commit install     # Install git hooks

  4. Set up environment variables: Create a .env file in the project root with the following variables:

    # Strava API credentials (required for Strava integration, generate with the auth-strava command)
STRAVA_CLIENT_ID=your_client_id
STRAVA_CLIENT_SECRET=your_client_secret
STRAVA_ACCESS_TOKEN=your_access_token
STRAVA_REFRESH_TOKEN=your_refresh_token
STRAVA_TOKEN_EXPIRES=token_expiration_timestamp

# RideWithGPS credentials (required for RWGPS integration)
RIDEWITHGPS_EMAIL=your_email
RIDEWITHGPS_PASSWORD=your_password
RIDEWITHGPS_KEY=your_api_key

# Garmin Connect credentials (required for Garmin integration)
GARMIN_EMAIL=your_email
GARMINTOKENS=~/.garminconnect

    Note: You can get Strava API credentials by creating an application at https://www.strava.com/settings/api, RideWithGPS credentials at https://ridewithgps.com/api, and Garmin Connect credentials by using your existing Garmin Connect account.

  5. Prepare your data:

    • Place your exported Strava activity files in a folder such as export_12345/ in the repo root.
    • If you're not using Strava export, place your files in export_12345/activities/ in the repo root.
    • (Optional) Place your exercise spreadsheet at ~/Documents/exerciselog.xlsx.

Authenticating with Strava

To use Strava API features, you need to authenticate and get an access token.

  1. Set your Strava API credentials as environment variables:

    export STRAVA_CLIENT_ID=your_client_id
export STRAVA_CLIENT_SECRET=your_client_secret

  2. Run the Strava authentication command:

    python -m fitler auth-strava

    This will guide you through the OAuth process and print an access token. Set it in your environment:

    export STRAVA_ACCESS_TOKEN=your_access_token

Authenticating with Garmin Connect

To use Garmin Connect API features, you need to authenticate and store OAuth tokens.

  1. Set your Garmin Connect credentials as environment variables (optional):

    export GARMIN_EMAIL=your_email
export GARMINTOKENS=~/.garminconnect

  2. Run the Garmin authentication command:

    python -m fitler auth-garmin

    This will prompt for your email and password, handle any required MFA, and automatically generate and store OAuth tokens that are valid for about a year. The tokens will be reused automatically for future API calls.

Running Fitler

You can use the CLI for various commands:

python -m fitler --help
python -m fitler configure
python -m fitler auth-strava
python -m fitler auth-garmin
python -m fitler pull --date 2025-08
python -m fitler sync-month 2025-08
python -m fitler reset --date 2025-08
  • configure – Set up paths and API credentials.
  • auth-strava – Authenticate with Strava and get an access token.
  • sync – Sync and match activities from all sources.
  • help – Show usage and documentation.

You can also use the Python API in your own scripts to process files, sync with providers, or analyze your data.

Running Tests

Fitler uses pytest for testing. To run all tests:

python -m pytest --cov=fitler --cov-report=term-missing -v

Test files are in the tests/ directory and mirror the package structure.

Packaging & Publishing to PyPI

To prepare and publish the package:

  1. Update version and metadata in setup.py and setup.cfg.
  2. Build the package:
    python -m build
  3. Upload to PyPI (requires twine):
    twine upload dist/*

Contributing

PRs and issues are welcome! See the TODO section in this README for ideas and next steps.

Development

This is a monorepo containing both the Python package and the static website.

Repository Structure

fitler/
├── .devcontainer/       # Development container configuration
├── .github/workflows/   # CI/CD pipelines
├── app/                 # Web dashboard (Flask)
├── fitler/              # Python package source
├── tests/               # Python tests
├── site/                # Static website source
│   ├── src/             # Website source files
│   ├── scripts/         # Build scripts
│   └── dist/            # Built website (generated)
├── pyproject.toml       # Python package config
├── ruff.toml           # Python linting configuration
├── dev.sh              # Start web dashboard
└── README.md           # This file (also used for website)

Web Dashboard

For local development, Fitler includes a simple web dashboard to view configuration and database status:

# Start the web dashboard
./dev.sh

Visit http://localhost:5000 to see:

  • 📊 Configuration status from fitler_config.json
  • 🔌 Provider settings (enabled/disabled, priorities)
  • 💾 Database information (size, tables, row counts)
  • 🔗 API endpoints for programmatic access

The dashboard provides a quick way to verify your Fitler setup without running CLI commands.

Development Tools

Python Development:

  • Ruff: Fast linting, formatting, and import sorting (replaces Black, Flake8, isort, Pylint)
  • MyPy: Static type checking
  • Pytest: Test runner with coverage
  • Pre-commit: Git hooks for automated code quality

Web Development:

  • Node.js 18: Runtime environment
  • Vite: Build system and dev server
  • ESLint: JavaScript linting
  • Stylelint: CSS linting
  • Prettier: Code formatting

Development Commands

Python:

# Run tests
python -m pytest -v

# Lint and format code
ruff check fitler/ tests/           # Check for issues
ruff check --fix fitler/ tests/     # Auto-fix issues
ruff format fitler/ tests/          # Format code

# Type checking
mypy fitler/

# Run CLI
python -m fitler --help

Website:

cd site/

# Install dependencies
npm install

# Development server (localhost:3000)
npm run dev

# Build for production
npm run build

# Lint and format
npm run lint
npm run format

Quality Assurance:

# Run all pre-commit hooks
pre-commit run --all-files

# Verify development environment
.devcontainer/verify.sh

VS Code Integration

The development container automatically configures VS Code with:

  • Format on save for all file types
  • Automatic import organization
  • Error highlighting for Python, JavaScript, CSS
  • Integrated terminal with proper environment
  • All necessary extensions pre-installed

Available VS Code Tasks (Ctrl+Shift+P → "Tasks: Run Task"):

  • Python: Run Tests - Run all Python tests
  • Python: Lint All - Run Python linting
  • DevContainer: Verify Setup - Verify environment health

Website Development

The website at fitler.net automatically includes content from this README.md file:

  1. Start development server: cd site && npm run dev
  2. Edit files in site/src/ or update README.md
  3. Site rebuilds automatically with changes
  4. Build for production: npm run build

The website is automatically deployed when changes are pushed to the main branch.

License

This project is licensed under the Creative Commons Attribution-NonCommercial 4.0 International (CC BY-NC 4.0). See the LICENSE file for details.

Getting things back out into spreadsheet

sqlite3 metadata.sqlite3
.headers on
.mode csv
.output metadata.csv
SELECT date,activity_type,location_name,city,state,temperature,equipment,duration_hms,max_speed,avg_heart_rate,max_heart_rate,calories,max_elevation,total_elevation_gain,with_names,avg_cadence,strava_id,garmin_id,ridewithgps_id,notes from ActivityMetadata where source="Main";
.quit

TODO

* Next month to fix:  `python -m fitler sync-month 2024-03`
* File provider manually fixed, go through other providers and manually fix them to work the ~same way. make sure we're not making API calls if the month is synced.
* Fix strava gear matching to work for running shoes.
* Fix "create" in providers to create_from_activity, and get all that out of sync_month
* Write some tests...
* Get everything out of gpx files: https://pypi.org/project/gpxpy/  (basics are in, need to fill out metadata, add more fields to db!)
* Get everything out of tcx files: https://pypi.org/project/python-tcxparser/ (basics are in, need to fill out metadata, add more fields to db!)
* Get everything out of fit files: https://github.com/dtcooper/python-fitparse/ (basics are in, need to fill out metadata, add more fields to db!)
* Get everything out of KML files: https://pypi.org/project/pykml/
* Get everything out of a spreadsheet with headers: https://pypi.org/project/openpyxl/ (basics are in, work better with headers)

* Output as all fit (lib already included)
* Output as all tcx (lib already included)
* Output as all gpx (lib already included)
* Output as all kml (lib already included)
* Output as all geojson: https://pypi.org/project/geojson/

* Load files from S3 bucket or somewhere else instead of local: https://pypi.org/project/boto3/

* What is in TrainingPeaks?
* What is in Wandrer.earth?
* What about the weather?
* What about choochoo?
* What else?

* switch to fitdecode
